Animation

Animations are declarative: an animate prop carries track specs, they ride the command stream once, and the render thread interpolates every frame per vsync — zero JS work per frame, no React re-render. createAnimation() mints a spec with an attached controller for imperative playback control.

import { createAnimation } from "@scumble/react";
import type { AnimationController, ControlledAnimationSpec } from "@scumble/react";

Every shape (and Canvas/Group) accepts animate with one track per property and many tracks per node. Plain track specs work as-is; null/false array entries are filtered, and an empty array (or null) clears the node's animations.

import { Canvas, Rect, createAnimation } from "@scumble/react";

const spin = createAnimation({
  property: "rotate",
  from: 0,
  to: 360,
  duration: 3000,
  iterations: Infinity,
});

export function SpinScene() {
  return (
    <Canvas style={{ width: "100%", height: 200 }}>
      <Rect x={60} y={60} width={80} height={80} color="#f59e0b" animate={spin} />
    </Canvas>
  );
}

createAnimation

Mint a controllable animation spec: the return value is a plain track spec usable directly as animate, with .controller as the imperative surface. No hooks, no refs — a spec held in user code is stable across re-renders by construction.

function createAnimation(spec: AnimationTrackSpec): ControlledAnimationSpec;

Control dispatches ride the owning canvas's invoke lane (canvases register themselves while mounted; a dispatch broadcasts to every live canvas — the one holding the handle executes). Native completion events fire on the canvas root and are demuxed back to controller.onFinish by handle.

AnimationTrackSpec — track fields

Field	Type	Default	Description
property	AnimatedPropertyName	—	The animated property — one of the 16 below. Required.
from	number | Color | [number, number]	—	Start value — sugar for a two-keyframe track. A [sx, sy] pair for scale; a Color for the color properties.
to	number | Color | [number, number]	—	End value. See from.
keyframes	KeyframeSpec[]	—	Explicit keyframes — the alternative to from/to.
duration	number	300	Milliseconds per iteration.
delay	number	0	Milliseconds before the first iteration.
iterations	number	1	Iteration count; Infinity/negative = infinite.
autoReverse	boolean	false	Even iterations forward, odd reversed — CSS alternate.
fill	"none" | "forwards"	"none"	What happens after the last iteration: return to base values, or pin the end value.
easing	EasingSpec	"linear"	Track-default easing; keyframes without their own inherit it.
cx	number	0	rotate/scale pivot center x.
cy	number	0	rotate/scale pivot center y.

EasingSpec is a preset name — "linear", "ease-in", "ease-out", "ease-in-out", "step-start", "step-end" — or cubic-bezier control points [x1, y1, x2, y2].

KeyframeSpec — keyframe fields

Field	Type	Default	Description
offset	number	—	Position within one iteration, [0, 1]. Omitted offsets are evened out; the first/last are pinned to 0/1.
value	number	—	Scalar value slot.
value2	number	—	Second scalar slot — scale's sy.
color	Color	—	Color slot (the color properties use this instead of the scalars).
easing	EasingSpec	—	Easing of the segment starting at this keyframe; omitted → the track's.

Animatable properties

The 16 properties accepted as property (AnimatedPropertyName):

Property	Value type	Notes
opacity	number	0–1 alpha.
translateX	number	X offset (px).
translateY	number	Y offset (px).
rotate	number	Degrees (not radians); pivots at the track's cx/cy.
scale	number | [number, number]	Uniform, or [sx, sy].
pathStart	number	<Path> trim start — [0, 1] path-length fraction.
pathEnd	number	<Path> trim end — [0, 1] fraction.
fillColor	Color	Fill color.
strokeColor	Color	Stroke color.
x	number	Left edge (rect-family, <Image>, <Paragraph>).
y	number	Top edge.
width	number	Width.
height	number	Height.
cx	number	Center x (<Circle>, <Ellipse>).
cy	number	Center y.
r	number	Radius (<Circle>).

AnimationController

The imperative surface on a createAnimation() spec — the spec itself. Control is node-granular: one handle steers all of the node's tracks.

spin.controller.pause();
spin.controller.seekTo(1500);
spin.controller.onFinish(() => console.log("done"));

Member	Signature	Description
handle	readonly handle: string	The minted playback handle — what the native tree registers.
pause	pause(): void	Freeze in place (the overlay holds; the driver goes idle).
play	play(): void	Resume from the freeze, or restart an idle/finished node from t=0.
seekTo	seekTo(timeMs: number): void	Jump the timeline (ms, delay counts); repaints immediately.
cancel	cancel(): void	Drop the tracks and return to base values (fires no finish event).
onFinish	onFinish(callback: (() => void) | null): void	Set (or, with null, clear) the natural-completion callback.

ControlledAnimationSpec

The return type of createAnimation() — a full AnimationTrackSpec with a minted playback handle and controller attached:

interface ControlledAnimationSpec extends AnimationTrackSpec {
  controller: AnimationController;
}

Hand it to any node's animate prop as-is; use .controller from event handlers for imperative playback control. Plain track specs (without a controller) remain valid animate values — they just run uncontrolled, start to finish.
