Canvas & Group

The two container components: <Canvas> is the GPU drawing surface every scene renders into, and <Group> applies transforms, paint inheritance, and clipping to a subtree.

import { Canvas, Group } from "@scumble/react";

<Canvas>

Root canvas — renders the native <scumble-canvas> (Android OpenGL ES / Vulkan, iOS Metal). Size comes from style like any Lynx view; children are positioned in that physical space by default. viewPort opts into a logical coordinate space (the SVG viewBox equivalent).

While mounted, the canvas is also the transport for animation playback control: createAnimation().controller dispatches through this root's invoke lane, and the canvas demuxes the native animation-finish events back to the right controller.

// 1:1 physical pixels
<Canvas style={{ width: 200, height: 100 }}>
  <Rect x={0} y={0} width={50} height={50} color="red" />
</Canvas>

// logical 100x100 space, scaled to fit (xMidYMid meet)
<Canvas style={{ width: "100%", height: 160 }} viewPort={{ width: 100, height: 100 }}>
  <Rect x={5} y={5} width={40} height={40} color="red" />
</Canvas>

Props

Prop	Type	Default	Description
children	ReactNode	—	The scene: shapes, groups, shaders, filters.
style	Lynx view style	—	Standard Lynx view style object — the canvas size comes from here.
viewPort	{ x?: number; y?: number; width: number; height: number }	—	Logical viewport (SVG viewBox). When set, child geometry authored in this logical pixel space is scaled by the renderer to fit the canvas (preserveAspectRatio = xMidYMid meet). Omit for 1:1 physical pixels.
animate	AnimationSpec | AnimationSpec[] | null	—	Declarative native animations on the canvas root node (whole-canvas transform/opacity). Same semantics as the shared animate prop.

<Group>

Grouping node — applies a transform, optional clip children, and paint inheritance to its subtree.

• Transforms cascade: each group's matrix pre-multiplies onto the inherited one (standard 2D scene-graph semantics, inside the canvas viewPort).
• Paint inheritance: a Group's color/style/opacity/stroke attributes/dash — and a direct gradient child or <Paint> override — apply to every descendant that doesn't set its own. A color-less <Circle> under <Group color="red"> fills red. opacity multiplies down the tree. Not inherited: geometry, display/visibility.

<Group transform={{ translateX: 10, translateY: 10 }}>
  <Circle cx={0} cy={0} radius={20} color="red" />
</Group>

<Group color="#3b82f6" opacity={0.8}>
  <ClipRRect x={0} y={0} width={100} height={80} radii={12} />
  <Circle cx={50} cy={40} radius={45} />
</Group>

Props

GroupProps extends GraphicProps — the Group accepts the full shared graphic props table and adds no props of its own. transform applies to the whole subtree, children carries the scene graph (shapes, clip children, shader/<Paint> children).
