Path2D & Path Ops

Path2D is a command-style path builder (re-exported from @scumble/graphics, the same shape as the Web Canvas Path2D) for authoring paths imperatively instead of via an SVG d string. A Path2D and a d string are interchangeable wherever a path prop is accepted — <Path> and <ClipPath>.

import { Path, Path2D } from "@scumble/react";
import type { PathOpName } from "@scumble/react";

Geometry is authored in the same space as a d string (logical pixels when the canvas has a viewPort). Relative commands, smooth-cubic/quad (S/T), and H/V are string-syntax conveniences only — here you write the resolved absolute forms directly.

Path2D

All instance methods are chainable (moveTo(…).lineTo(…).close()).

import { Canvas, Path, Path2D } from "@scumble/react";

const p = new Path2D().moveTo(10, 10).lineTo(90, 90).close();

<Canvas style={{ width: 200, height: 200 }}>
  <Path path={p} color="#22c55e" />
</Canvas>;

Methods

Method	Returns	Description
moveTo(x, y)	this	Start a new subpath at (x, y).
lineTo(x, y)	this	Line from the current point to (x, y).
quadTo(cpx, cpy, x, y)	this	Quadratic Bézier with control point (cpx, cpy) to (x, y).
cubicTo(cp1x, cp1y, cp2x, cp2y, x, y)	this	Cubic Bézier with two control points to (x, y).
arcTo(rx, ry, xAxisRotation, largeArc, sweep, x, y)	this	SVG-style arc to (x, y). largeArc/sweep are booleans (the 0/1 flag bytes the renderer expects — same as the A command in a d string).
close()	this	Close the current subpath.
addPath(other)	this	Append another Path2D's commands verbatim.
addRect(x, y, w, h)	this	Rectangle as a closed subpath.
addCircle(cx, cy, r)	this	Circle (center + radius), approximated by four cubic Béziers.
addOval(x, y, w, h)	this	Ellipse inscribed in (x, y, w, h), approximated by four cubic Béziers.
addRoundedRect(x, y, w, h, rx, ry?)	this	Rounded rectangle via four elliptical arcs; ry defaults to rx, and both are clamped to half the respective side.
reset()	this	Clear all commands.
toBytes()	ArrayBuffer	Serialize the commands to the nested PathCommandList FlatBuffer the native prop channel consumes (the component layer base64-encodes it).
toOpBytes()	ArrayBuffer | null	Serialize a boolean composition (see op below) to a PathOpList FlatBuffer; null on a plain (command-style) instance.

Path2D.op() — boolean compositions

static op(one: string | Path2D, two: string | Path2D, op: PathOpName): Path2D;

Lazily combine two paths with a boolean operation (Skia path ops). Nothing is evaluated in JS: this only records the composition, and the native renderer evaluates the tree at draw time (skity PathOp::Execute, a left fold; an operand whose evaluation fails is skipped). There is no channel back to JS — that is why the composition is lazy and transport-side.

Operands accept an SVG d string or a Path2D — including other op-composed instances, so compositions nest arbitrarily:

const circle = new Path2D().addCircle(50, 50, 40);
const square = new Path2D().addRect(10, 10, 80, 80);

// ((circle ∪ square) − circle): a square with a circular hole
const frame = Path2D.op(Path2D.op(circle, square, "union"), circle, "difference");

<Path path={frame} color="#3b82f6" />;

op() returns a fresh op-composed Path2D; the operands are not modified.

PathOpName

The four boolean operation names (Skia/skity path ops — there is no reverseDifference):

type PathOpName = "difference" | "intersect" | "union" | "xor";

Value	Result
"difference"	one minus two.
"intersect"	The area covered by both.
"union"	The area covered by either.
"xor"	The area covered by exactly one.
