Filters

Paint filter components — declarative children of a shape (or of a <Paint>), like the shaders. Each is data-only and renders nothing itself: the parent shape collects the props and serializes them into its paint.

import { Blur, DropShadow, ColorMatrix, ColorBlend, MaskBlur } from "@scumble/react";

<Blur>/<DropShadow> are image filters (they render the shape into a layer first), <ColorMatrix>/<ColorBlend> are color filters, and <MaskBlur> is a mask filter. Several filters of the same kind compose in declaration order — the first declared applies first (innermost). Like shaders, a filter child routes to the paint the shape actually draws with: inside <Paint style="stroke"> it targets the stroke paint.

<Circle cx={60} cy={60} radius={40} color="#3b82f6">
  <DropShadow dx={0} dy={8} blur={12} color="#00000055" />
</Circle>

<Blur>

Image filter: blur the shape's rendered layer.

<Rect x={20} y={20} width={120} height={80} color="#3b82f6">
  <Blur blur={8} />
</Rect>

Props

Prop	Type	Default	Description
blur	number | { x: number; y: number }	—	Blur sigma in px — a number blurs uniformly, {x, y} per axis. Required.

<DropShadow>

Image filter: drop a blurred, colored copy of the shape behind it.

<Rect x={20} y={20} width={120} height={80} color="#f59e0b">
  <DropShadow dx={4} dy={6} blur={10} color="#00000066" />
</Rect>

Props

Prop	Type	Default	Description
dx	number	—	Shadow offset x (px). Required.
dy	number	—	Shadow offset y (px). Required.
blur	number	—	Shadow blur sigma (px, uniform). Required.
color	Color	—	Shadow color. Required. (inner/shadowOnly variants are not supported.)

<ColorMatrix>

Color filter: a per-pixel 4×5 color matrix — grayscale, sepia, channel swaps, and other linear color transforms.

const grayscale = [
  0.2126, 0.7152, 0.0722, 0, 0, 0.2126, 0.7152, 0.0722, 0, 0, 0.2126, 0.7152, 0.0722, 0, 0, 0, 0, 0,
  1, 0,
];

<Rect x={20} y={20} width={120} height={80} color="#3b82f6">
  <ColorMatrix matrix={grayscale} />
</Rect>;

Props

Prop	Type	Default	Description
matrix	number[]	—	20 numbers, row-major 4×5 (Skia layout: R/G/B/A rows + a translation column). An invalid matrix (wrong length / non-finite) is dropped. Required.

<ColorBlend>

Color filter: blend a constant color onto the source, with any of the 28 blend modes.

<Rect x={20} y={20} width={120} height={80} color="#3b82f6">
  <ColorBlend mode="multiply" color="#ffcc00" />
</Rect>

Props

Prop	Type	Default	Description
mode	BlendMode	—	How the blend color combines with the source color. Required.
color	Color	—	The blend color. Required.

<MaskBlur>

Mask filter: feather the shape's alpha mask (Skia's blur MaskFilter — the fuzzy-edge sibling of <Blur>, without the separate render layer).

<Rect x={20} y={20} width={120} height={80} color="#ef4444">
  <MaskBlur blur={10} />
</Rect>

Props

Prop	Type	Default	Description
blur	number	—	Feather radius (px). Required.
style	"normal" | "solid" | "outer" | "inner"	"normal"	How the mask treats its inside (Skia BlurStyle): "normal" is fuzzy inside and outside, "solid" solid inside / fuzzy outside, "outer" fuzzy outside only, "inner" fuzzy inside only.
